The HT0525c H-hinge is a premium round paumelle with cover plates for a modern, minimalist aesthetic. This hinge is manufactured from solid brass extrusion with a fixed stainless steel pin and concealed bearing.

Leaf thickness below includes cover plate thickness.

H Theophile Diagram HT0525c.jpg

LEAF HT. WIDTH KNUCKLE LEAF
6" 3-3/4" 5/8" .208"
6-1/2" 4" 5/8" .208"
6-1/2" 4-1/2" 5/8" .208"
HT0525
